- 5.5″ Wide Color Gamut Monitor
- 2000 cd/m² Touchscreen
- Wired and Wireless Camera Control
- HDMI and SDI Input/Output Ports
- SDI Output with New 3D LUTs
- Dual-Screen Monitoring
- User Calibration, Seven Custom Pages
- Log and Custom False Color
- Recording Synchronized Fan
PORTKEYS BM5IV WR 5.5″ HDMI/SDI Touchscreen Monitor with Camera Control








PORTKEYS BM5IV WR 5.5″ HDMI/SDI Touchscreen Monitor with Camera Control
100 DT / Day (ex VAT)
Use the PORTKEYS BM5IV WR 5.5″ HDMI/SDI Touchscreen Monitor and its wired and wireless camera control options to monitor your image and focus accurately, no matter if you’re shooting on location or in the studio. This ultrabright 2000 cd/m² onboard monitor features a wide color gamut, a durable aluminum build, and both HDMI and 3G-SDI video inputs and outputs. It supports HDMI/SDI signal conversion and can output 3D LUTs via its SDI output port. Wired control is available for select RED, Sony, Blackmagic Design, Canon, Panasonic, and Z CAM cameras, as well as the Tilta Nucleus-M wireless lens motors. Wireless 2.4 GHz signals allow control over compatible RED, ARRI, Nikon, Sony, Canon, and Panasonic models.
Specs
Display Size |
5.5″ / 14.0 cm
|
Native Resolution |
1920 x 1080
|
Touchscreen |
Yes
|
HDR Support |
Yes
|
Video I/O |
1x HDMI 2.0 Input
1x HDMI 2.0 Output 1x BNC (3G-SDI) Input 1x BNC (3G-SDI) Outpu |
Media/Memory Card Slot |
No
|
Video Format |
HDMI
DCI 4K: 60/59.94/50/30/29.97/25/24/23.98 UHD 4K: 60/59.94/50/30/29.97/25/24/23.98 1080p: 60/59.94/50/30/29.97/25/24/23.98 1080PsF: 29.97/25/24/23.98 1080i: 60/59.94/50 720p: 60/59.94/50 576p: 50 576i: 50 480p: 60/59.94 480i: 60/59.94 SDI (4:2:2 YUV) 1080p: 60/59.94/50/30/29.97/25/24/23.98 1080PsF: 30/29.97/25/24/23.98 1080i: 60/59.94/50 720p: 60/59.94/50 SDI (4:4:4) 1080p: 30/29.97/25/24/23.98 1080PsF: 30/29.97/25/24/23.98 1080i: 60/59.94/50 720p: 60/59.94/5 |
Battery |
1x L-Series Mount on Fixed Plate
|
Power Consumption |
17 W (Maximum)
|
Display
Panel Type |
LCD
|
Display Size |
5.5″ / 14.0 cm
|
Native Resolution |
1920 x 1080
|
Aspect Ratio |
16:9
|
Viewing Angle |
Horizontal: 178°
Vertical: 178° |
Touchscreen |
Yes
|
Maximum Brightness |
2000 nits / cd/m2
|
Contrast Ratio |
1000:1
|
Color Support |
16.7 Million Colors (8-Bit+FRC)
|
HDR Support |
Yes
|
Color Gamut |
100% Rec. 709
85% DCI-P3 |
LUT Support |
Yes
|
Image Controls |
Anamorphic De-Squeeze, Check Field, False Color, Focus Peaking, Histogram, Vectorscope, Waveform, Zebra
|
Inputs/Outputs
Video I/O |
1x HDMI 2.0 Input
1x HDMI 2.0 Output 1x BNC (3G-SDI) Input 1x BNC (3G-SDI) Output |
Embedded Audio |
HDMI/SDI
|
Audio I/O |
1x 1/8″ / 3.5 mm Headphone Output
|
Power I/O |
1x Aviation 4-Pin (24 VDC) Input
1x LEMO 2-Pin (24 VDC) Input |
Other I/O |
1x Unspecified 5-Pin (Serial) Input
1x USB-A (Firmware/LUT Upload) 1x Mini-USB (Camera Control) |
Media/Memory Card Slot |
No
|
Wireless
Wi-Fi |
Yes
|
Bluetooth |
No
|
Mobile App Compatible |
No
|
Format Support
Video Format |
HDMI
DCI 4K: 60/59.94/50/30/29.97/25/24/23.98 UHD 4K: 60/59.94/50/30/29.97/25/24/23.98 1080p: 60/59.94/50/30/29.97/25/24/23.98 1080PsF: 29.97/25/24/23.98 1080i: 60/59.94/50 720p: 60/59.94/50 576p: 50 576i: 50 480p: 60/59.94 480i: 60/59.94 SDI (4:2:2 YUV) 1080p: 60/59.94/50/30/29.97/25/24/23.98 1080PsF: 30/29.97/25/24/23.98 1080i: 60/59.94/50 720p: 60/59.94/50 SDI (4:4:4) 1080p: 30/29.97/25/24/23.98 1080PsF: 30/29.97/25/24/23.98 1080i: 60/59.94/50 720p: 60/59.94/50 |
Video Signal Conversion |
HDMI to SDI
SDI to HDMI |
Power
Input Power |
7 to 24 VDC
|
Battery |
1x L-Series Mount on Fixed Plate
|
Power Consumption |
17 W (Maximum)
|
Mounting
Tripod/Accessory Mounting |
Top/Bottom/Right
1x 1/4″-20 Female |
General
Dimensions |
5.7 x 3.6 x 1.6″ / 145.4 x 91.4 x 39.6 mm
|
Weight |
0.8 lb / 362.00 g
|
