- For Mobile Journalist, Videographer
- ME 2-II Omnidirectional Lav Mic
- Rugged Bodypack Transmitter
- Diversity Camera-Mount Receiver
- 1680 Auto-Scan Frequencies
- Advanced Controls for Flexible Use
- Daylight-Readable Display
- 8-Hour AA Batteries
- Up to 12 Mics on Set / 330′ Range
Sennheiser EW 112P G4 Camera-Mount Wireless Omni Lavalier Microphone System (B: 626 to 668 MHz)
Sennheiser EW 112P G4 Camera-Mount Wireless Omni Lavalier Microphone System (B: 626 to 668 MHz)
60 DT / Day (ex VAT)
The Sennheiser EW 112P G4 camera-mount wireless lavalier microphone system features the proven combination of reliability, flexible control, and broadcast-quality sound that has made the EW Series an industry standard for videographers, journalists, and content creators all over the world.The EW 112P G4 gives you the tools to adapt and meet the wireless challenges that inevitably arise on set. The frequency scan function automatically searches for the cleanest frequency at your location, while the adjustable input sensitivity on the transmitter accommodates mic levels ranging from booming voices to quiet speech, and even line-level audio.The system includes the improved ME 2-II omnidirectional lavalier mic, a bodypack transmitter, and a camera-mount receiver. It connects to a camcorder or a DSLR/mirrorless camera to capture crisp-sounding speech or dialog for projects ranging from documentaries to wedding videos, corporate spots, and hands-free interviews.The EW 112P G4 is backward-compatible with previous evolution systems, giving you the ability to mix and match G4/G3/G2/G1 receivers or bodypack, handheld, and plug-on transmitters. It is also compatible with EW 500 systems.
Specs
Sennheiser EW 112P G4 Specs
System
Wireless Technology | Analog UHF |
Number of RF Channel Frequencies | 1680 |
Included Transmitters | 1 x Bodypack with Microphone |
Diversity | Antenna Diversity |
RF Frequency Band | B:626 to 668 MHz |
RF Bandwidth | 42 MHz |
Frequency Step Size | 25 kHz |
Max Operating Range | 330′ / 100.6 m (Line of Sight) |
Max Transmitters per Band | 12 |
Deviation | 48 kHz (Peak) |
Modulation | Wideband FM |
Receiver
Receiver Type | Camera-Mount |
Mounting Options | Shoe-Mount (with Included Hardware) |
Antenna | 1 x Flexible Whip, Fixed |
Number of Audio Channels | 1 |
Audio I/O | 1 x 1/8″ / 3.5 mm TRS Female Unbalanced Output (Lockable) |
Gain Range | 42 dB (6 dB Steps) |
Audio Output Level | +12 dBu |
Squelch | 5 to 25 dBμV |
Adjacent Channel Isolation | >65 dB |
Power Requirements | Battery |
Battery Type | 2 x AA |
Approx. Battery Life | 8 Hours (Alkaline) |
Display & Indicators | 1 x Backlit LCD (Battery Status, Output Level, RF Level) |
Housing | Metal |
Operating Temperature | 14 to 131°F / -10 to 55°C |
Dimensions | 2.5 x 3.2 x 0.9″ / 64 x 82 x 24 mm |
Weight | 5.6 oz / 160 g (with Batteries) |
Transmitter
Transmitter Type | Bodypack |
RF Output Power | 30 mW |
Audio I/O | 1 x 1/8″ / 3.5 mm TRS Female Unbalanced Input (Lockable) |
Muting | Mute Switch |
Audio Input Level | 3 V RMS (Max) |
Gain Range | 60 dB (3 dB Steps) |
Frequency Response | 80 Hz to 18 kHz (Mic)25 Hz to 18 kHz (Line) |
Sync Method | IR |
Antenna | 1 x Flexible Whip, Fixed (Beltpack) |
Power Requirements | Battery |
Battery Type | 2 x AA (Included)1 x Sennheiser Accupack (Not Included) |
Approx. Battery Life | 8 Hours (Alkaline) |
Display & Indicators | 1 x Backlit LCD (Audio Level, Battery Status, Signal Strength) |
Housing | Metal |
Dimensions | 2.5 x 3.2 x 0.9″ / 64 x 82 x 24 mm |
Weight | 5.6 oz / 160 g (with Batteries) |
Microphone
Microphone Type | Lavalier |
Sound Field | Mono |
Capsule | Electret Condenser |
Polar Pattern | Omnidirectional |
Frequency Range | 50 Hz to 18 kHz |
Equivalent Noise Level | 36 dB |
Maximum SPL | 130 dB SPL Peak |
Sensitivity | 20 mV/Pa |
Output Connectors | 1 x 1/8″ / 3.5 mm TRS Male Unbalanced (Lockable) |
Cable Length | 5.25′ / 1.6 m |
Operating Voltage | 7.5 V |
